CNC Vertical Gear Head (2 Speeds)
IK-V6000
CNC Milling Head
CNC Milling Head CNC Milling Head CNC Milling Head CNC Milling Head CNC Milling Head CNC Milling Head
- 1. The IK milling head, which fits your current milling machines and special purpose machines, can take place of your current milling heads and upgrade your machines.
- 2. This product with gear-type construction is very powerful and can creat a maximum machining efficiency for you
- 3. Spindle speed change has high and low two stage.
- 4. This product can be installed to a computer-controlled vertical milling machine and a special purpose machine.
- 5. This products doesn't include a servo motor or servo controller.
- 6. The IK CNC milling head series has three kinds of products.
| Model | Unit | IK-V6000 | |
|---|---|---|---|
| SPINDLE | |||
| Spindle Type | BT50 | ||
| Spindle Speed | rpm | 6000 | |
| Speed Change | Hign / Low | ||
| DEEP | |||
| Distance from Spindle to Connector | mm | 470 | |
| GEAR RATIO | |||
| High Speed | 1 : 1 | ||
| Low Speed | 1 : 4 | ||
| Base Speed | rpm | 375 | |
| ELECTRIC USE STANDARD | |||
| Spindle Motor | Kw/Hp | 11/15 | 22/30 |
| Spindle Motor Spindle | Φ48 | Φ55 | |
| Gear Shift | rpm | 1500 | |
| STANDARD ACCESSORIES (● INCLUDE IN PRODUCT) | |||
| Spindle Motor (Φ48) | ● | - | |
| Spindle Motor (Φ55) | - | ● | |
| Lock Knife Block | ● | ||
| Shift Cylinder | ● | ||
| Oil Pressure Pipe | ● | ||
| OPTIONAL ACCESSORIES (○ APOLEGAMY) | |||
| CNC Gear Milling Head - Vertical Spindle (6000RPM/BT50) |
○ | ||
| Country of Origin | Taiwan | ||
| Weight (Approximate) | kg | 532 | |
| Warranty | 1 year (non artificial mistake) | ||
| Note: This product does not contain a servo motor. Recommended specifications §Spindle servo motor ( 11Kw / 15Hp or 22 Kw/30Hp ) ※Please provide a servo motor sizes. |
|||
